In-line CNC Coordinate Measuring System "MACH Series"
Coordinate measuring systems for production lines MACH Series
The MACH Series is a coordinate measuring machine designed for production lines, engineered with superior durability for stable, around‑the‑clock operation in factory environments. It delivers a significant reduction in measuring time, assures accuracy across a wide temperature range, and provides enhanced safety and ease of maintenance. The MACH Series is widely used in the automotive industry both domestically and overseas.
*Please contact our sales team for details.
*Manufacturer:Mitutoyo Corporation（Japan）
Features
MACH-V
An Optimal and Flexible Measuring System in Place of Dedicated Gage Measurement in a Production Line.
MACH-V provides a flexible measurement system capable of replacing a series of gage measurements on a powertrain manufacturing line.
The high acceleration, high-speed probe movement results in high-throughput measurement.
Specifications
- High-speed drive up to a maximum of 866 mm/s
- Space-saving design helps installation in a production line
- Accuracy assurance throughout a wide temperature range (5 to 35 ℃)
- Improved dust resistance
- Improved ease of maintenance
- Higher speed and accuracy with barycentric drive
MACH-3A
Long-awaited Horizontal Coordinate Measuring System Appropriate for a Horizontal Machining Line.
This is a horizontal CNC coordinate measuring system that achieves high throughput by increased drive speed, acceleration, and measuring speed.
Space-saving and durability characteristics are compatible with line-side / in-line installation.
Specifications
- High-speed drive up to a maximum of 1,212 mm/s
- Space-saving design helps installation in a prodction line
- Accuracy assurance throughout a wide temperature range (5 to 40 ℃)
- Improved dust resistance
- Improved ease of maintenance
- Extremely high throughput
Specification table
| Resolution | Measuring range | Max. heigh of workpiece | Max. mass of workpiece | Max. drive acceleration | |
|
|
0.0001 mm | X 900 mm, Y 1,000 mm, Z 600 mm | 800 mm | 150 kg | Each axis 5,063 mm/s2, Max. combined acceleration 8,770 mm/s2 |
|
|
0.0001 mm | X 600 mm, Y 500 mm, Z 280 mm | ― | 200 kg | Each axis 6,860 mm/s2, Max. combined acceleration 11,882 mm/s2 |
*Actual specifications may vary depending on the options and peripheral equipment installed.
